0615N5M

    6mm Micro DC Coreless Motor

    Diameter：6mm  Length ：15mm  Voltage：3V 、6V Max. output power ：0.11W  Speed：12200-29500rpm

    • Applications

      Medical equipment and devices, healthcare products, automotive, robotics, and industrial automation

    • Options

       Lead wires length、Shaft length、Special coils、Gearheads

    • Unit Price

      Price upon request

Ask for datasheet Discuss customized products Ask for a quotation
Characteristics
  unit 01-122-3.0 02-185-3.0 03-295-6.0
Voltage V 3.0 3.0 6.0
Terminal resistance Ω 19.0 18.5 10.1
No-load speed rpm 12200 18500 29500
No-load current mA 10 18 20
Stall torque mNm 0.33 0.20 1.07
Stall current mA 160 160 590
Nominal torque mNm 0.01 0.05 0.30
Nominal speed rpm 8500 13770 21230
Nominal current mA 60 50 180
Max. output power W 0.11 0.09 0.83
Max. efficiency % 56 44 67
Back-EMF constant mV/rpm 0.2 0.1 0.2
Torque constant mNm/A 2.2 1.4 1.9
Speed/torque gradient rpm/mNm 37000 94600 27600
Rotor inertia gcm2 0.015 0.015 0.015
Weight g 2.5 2.5 2.5
